Seed Magnetic Separator
The Seed Magnetic Separator uses magnetic powder for highly effective removal of worm eaten seeds. The operation is applicable to a wide range of shelled crops from sunflower seeds to peanuts.
Service station over the country.
Provide relevant business resources for free overseas.
PRODUCT DESCRIPTION
The seed magnetic separator is mainly used to remove residual materials such as worm holes and cracked shells. This machine can screen sunflower seeds, peanuts and other shelled crops. The materials and magnetic powder are continuously stirred in the mixing tank, and then separated.screening - discharge, Continuing to repeat the above process, and finally separate the complete materials and the defective materials, The material separation rate of this machine can reach more than 99%, the magnetic powder content of the finished material is zero. The magnetic powder can be effectively recovered and recycled, Also the equipment can be used in various production lines or stand-alone.
1.Elevator
2.Body
3.Outlet
4.Roller
5.Conveying belt
6.Service Entrance
Magnetic powder
Worm eaten seeds
Final product
Product Features
Excellent separating rate
High capacity
Cycle operation
Easy regulation
Durable
MODEL PARAMETERS
| SEED MAGNETIC SEPARATOR | |
| Capacity(kg/h)* For sunflower seeds | 4500 |
| Selecting rate | 99% |
| Dimension(L* w*H）/m | 5.86*1.8*2.7 |
| Weight(t) | 3.6 |
| Power(kW) | 7.06 |
| Voltage(V) | 380 |
